Xerox WorkCentre 3119 Service Manual

Status Indicator RAPs
2-16 07/06 WorkCentre 3119
12 Cover Open RAP
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
Description
The Cover Open message is displayed when the front cover is closed.
The Cover Open message is not displayed when the front cover is open.
Check and Cause Solution
1. The tab on the front cover may be dam-
aged or broken.
1. Install a new front cover, PL 2.
2. The Cover Open Switch may be stuck or
faulty.
Note: There are two Cover Open Switches.
One is fitted on the Cover-M-Side R, PL 2 and
the other is mounted on the SMPS/HVPS, PL
1.
2. Check the cover open switch mounted on
the HVPS/SMPS using Engine Test Mode,
GP 4.
Check the connection between the cover
open switch, PL 2 and the SMPS/HVPS, PL
1.
Install new parts as necessary:
• Cover open switch, PL 2
• SMPS/HVPS, PL 1

Xerox WorkCentre 3119 Specifications

General

Print Technology	Laser
Print Speed	19 ppm
Print Resolution	600 x 600 dpi
Copy Speed	19 cpm
Copy Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Scanner Type	Flatbed
Memory (Standard)	32 MB
Operating System Compatibility	Windows, Mac
