Xerox WorkCentre 3119 Service Manual

Status Indicator RAPs
WorkCentre 3119 07/06 2-17
13 No Power RAP
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
Description
When system power is turned on the LCD panel does not come on.
Check and Cause Solution
1. Check the power supply cord, PL 1.
Check the SMPS/HVPS output using Engine
Test Mode, GP 4.
1. Install new parts as necessary:
• Power supply cord, PL 1
• SMPS/HVPS, PL 1
• Main PBA, PL 1
2. LCD panel does not come on but normal
start up sounds are heard.
2. Install a new PBA sub-panel, PL 8.

Xerox WorkCentre 3119 Specifications

General

Print Technology	Laser
Print Speed	19 ppm
Print Resolution	600 x 600 dpi
Copy Speed	19 cpm
Copy Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Scanner Type	Flatbed
Memory (Standard)	32 MB
Operating System Compatibility	Windows, Mac
