Xerox WorkCentre 3119 Service Manual

Spare Parts List
WorkCentre 3119 06/06 5-3
PL 1 Main Assembly
Item Part Number Description Remark
0 WORKCENTRE 3119
1 ELA HOU BASE-HOUSING
2 USB CABLE REFER TO PL 10, ITEM 5
3 105N02072 CBF-POWER CORD
4 FRAME ASSEMBLY REFER TO PL 3, ITEM 0
5 127N07521 TONER FAN (DC_HAWK) REP 11
6 062N00274 UNIT-HUMMING_VE LSU REP 10
7 CBF HARNESS-OPE
8 152N11596 CBF HARNESS-LSU
9 DRIVE ASSEMBLY REFER TO PL 6, ITEM 0
10 MOTOR HARNESS
11 TRANSFER ROLLER REP 16
11-1 022N02266 ROLLER TRANSFER SPONGE
11-2 PPR-SPACER_TR
11-3 007N01548 GEAR_TRANSFER
12 055N00289 SHIELD ENGINE ASSEMBLY REP 12
13 030N00705 BRACKET-P-INLET
14 105N02110 SMPS/HVPS 220V REP 14
105N02050 SMPS/HVPS 110V REP 14
15 140N63204 MAIN PBA REP 13
16 152N11597 CBF HARNESS-ENGINE
17 CASSETTE ASSEMBLY REFER TO PL 9, ITEM 0
18 SCAN ASSEMBLY REFER TO PL 7, ITEM 0
19 002N02611 REAR COVER REFER TO PL 2, ITEM 5
20 ELA UNIT-DEVE
21 CIS HARNESS BRACKET
22 ADJUSTABLE CABLE TIE
23 021N02254 CAP M LSU

Xerox WorkCentre 3119 Specifications

General

Print Technology	Laser
Print Speed	19 ppm
Print Resolution	600 x 600 dpi
Copy Speed	19 cpm
Copy Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Scanner Type	Flatbed
Memory (Standard)	32 MB
Operating System Compatibility	Windows, Mac
