Spare Parts List
WorkCentre 3119 06/06 5-7
PL 3 Frame Assembly (1)
Item Part Number Description Remark
0 001N00487 ELA UNIT-FRAME LOWER (220V)
001N00488 ELA UNIT-FRAME LOWER (110V)
1 FRAME_M_BASE
2 015N00548 PLATE_P_SAW
3
038N00408
PLATE-M-TR
4 GEAR-EXIT
5 HOLDER BEARING EXIT
6E-CLIP
7 022N02269 EXIT ROLLER REP 19
8 009N01522 SPRING-CS
9 019N00819 HOLDER-M_EXIT
10 PMO-M-ROLLER EXIT MAIN
11 PMO-M-ROLLER EXIT FR
12 PMO-GEAR_EXIT_DRV16
13 WASHER
14 GUIDE-M-KNOCK UP
15 IPR-P-TERMINAL DEV KEY
16 CRUM PBA REP 15
17 032N00433 PMO-PLATE GUIDE DEV RIGHT
18 PLATE-P-TERMINAL CR
19 IPR-P-TERMINAL CON
20 116N00241 MEC-TERMINAL
21 115N00870 HOUSING-M-TERMINAL
22 003N00947 PMO-LOCKER CST
23 120N00460 PMO ACTUATOR CVR OPEN
24 FOOT-FRONT
25 FOOT-BACK
26 IPR-P-GROUND_TR
27 FUSER UNIT REFER TO PL 5, ITEM 0
28 GUIDE-M-TR LOWER
29 IPR-P-GROUND_FUSER
30 SPRING ETC-GUIDE DEV
31 LABEL(R)-HV FUSER
32 022N02131 BRACKET-P-FEED
33 SPRING-TS
34 130N01375 CAM-M-PICK_UP
35 IPR-GROUND_DRIVE
36 IPR-GROUND_DRIVE2
37 RING-CS
38 121N01088 SOLENOID HB (BYPASS) REP 18
39 130N01376 SOLENOID HB (PICKUP) REP 18
40 RUBBER SEAT
41 032N00434 PMO-PLATE GUIDE DEV LEFT
