Xerox WorkCentre 3119 Service Manual

Spare Parts List
WorkCentre 3119 06/06 5-9
PL 4 Frame Assembly (2)
Item Part Number Description Remark
1SPRING TS
2 IPR-P-GROUND EARTH TR
3SPRING TS
4 022N02127 FEED SENSOR ACTUATOR
5 709N00007 BYPASS SENSOR ACTUATOR
6 121N01087 PAPER SENSOR ACTUATOR
7 FRAME EXT
8 022N02128 FEED ROLLER 1 REP 17
9SPRING-ETC
10 022N02129 PMO-BUSHING FEED
11 022N02130 FEED ROLLER REP 17
12 PMO-LOCKER CST
13 130N01378 PICKUP ROLLER REP 18
13-1 BUSH-M-PICKUP LEFT
13-2 SHAFT-P-PICKUP
13-3 STOPPER-PICKUP
13-4 PMO-IDLE-PICKUP
13-5 SPONGE-ROLLER-PICKUP
13-6 BUSH-M-PICKUP RIGHT
13-7 HOUSING-M-PICKUP
13-8 REINFORCEMENT BAR
14 GEAR IDLE 23
15 GEAR FEED 2
16 121N01141 MEA-UNIT_CLUTCH
16-1 GEAR FEED 1
16-2 PMO-COLLAR SPRING
16-3 SPRING TS
16-4 PMO-HUB CLUTCH
16-5 FEED1 SHAFT
17 130N01377 AS GEAR PICKUP
17-1 PMO-GEAR PICKUP B
17-2 PMO-GEAR PICKUP A
17-3 SPRING-CS
18 BUSH-M-FEED_IDLE
19 SPRING-ETC TR
20 SHAFT-FEED IDLE
21 038N00409 GUIDE PAPER
22 IPR-P-GROUND_GUIDE PAPER
23 115N00854 IPR-P-EARTH TRANSFER
24 062N00259 PTL LENS
25 HOLDER-PTL
26 140N62968 PTL PBA
27 PMO-BUSHING TR R
28 SPRING ETC-TR LEFT HAWK
29 BUSH-M-TR-LEFT
30 SHAFT FEED
