Xerox WorkCentre 3225

June 2014
6-22
Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual
Entering Diagnostic Mode
General Procedures and Information
NOTE: * Indicates that there is a function in Diagnostics that allows for entry of the serial
number using the keypad (3025NI). From Diagnostic Mode, (Ref. GP 1) select: [Data Set
Up>Set Serial Number] then, using the keypad, enter the serial number. Press the
<OK> button to confirm selections. This function allows numeric entries only. For
serial numbers containing alpha characters (letters) use the serial number writing tool;
USB_Serial.V1.02.exe.
Data Setup Caller ID Status:
Off/On
Busy Tone Status:
Off/On
F/W Upgrade Status:
Off/On
*Set Serial No. Enter machine serial
number
Format Flash Yes
Table 1 Diagnostic Mode Menu - Data Setup
Level 1 Level 2 Level 3 Level 4
Table 2 Diagnostic Mode Menu - Machine Test
Level 1 Level 2 Level 3 Level 4 Level 5 Level 6
Machine Test DC305 UI Test
(Ref. GP 9)
Press any key to
start
Modem Test Fsk ?
DRAM Test DRAM Test OK
ROM Test Press <OK>
Continuous DTMF DTMF # Line 1
DTMF *Line 2
Test Pattern Test Pattern 1 Yes/No
Test Pattern 2 Yes/No
Shading Test Shading & Print Yes/No
Scan Aging P.1...P.2...etc Press Stop button
to cancel
EDC Mode DC131 NVM Read/
Write
105 MHV Bias MHV DC K 50-900
106 Dev Bias Deve DC K 50-900
107 ATTR Bias THV K 50-900
109 Fuser Heat Ready Temp -10 - 10
110 LSU LD Power K 50-900
DC132 NVM Initial-
ize
Yes/No
DC330 Compo-
nent Control
100 Motor Main BLDC Status [Off]
Main BLDC Ready Status: [Low]
101 Clutch Tray 1 Pickup Status: [Off]
Registration Status: [Off]
Out Bin Full Low
102 Sensor Tray 1 Empty Status: {Low]
Feed Sens Status: [Low]
Regi Sens Status: [Low]
Exit Sens Status: [Low]
105 MHV Bias K MHV Bias Status: [Off]
