Xerox WorkCentre 3225 - Page 181

June 2014
Xerox
®
WorkCentre
®
3215/3225 Multifunction Printer Service Documentation
BSDs
7-9
A B C D E F G H J
1
2
3
4
5
6
9.1 XEROGRAPHICS
PL 4.1
MAIN PWB
HVPS PWB
PRINT MODULE
+3.3 VDC
+3 VDC CRUM
26
J30 P30
25
24
1
P100 J100
2
3
CRUM SIGNAL
CRUM SIGNAL
TRANSFER ENABLED
23
4
TRANSFER ON
6
21
TRANSFER ON
21
6
CHARGE ENABLED
17
10
DEVELOPER DC
19
8
1
J3 P3
3
4
2
CRUM
TRANSFER
ROLL
CHARGE
SUPPLY
ROLL
DEVELOPER
ROLL
PR DRUM
1
J10 P10
3
4
2
CRUM
+3.3 VDC
DC COM
+3 VDC
DC COM
WITH ALL IN ONE
PRINT MODULE
CRUM SIGNAL
CRUM SIGNAL
PL 4.1
