Xerox WorkCentre 3225 - Page 182

Xerox
®
WorkCentre
®
3215/3225 Multifunction Printer Service Documentation
June 2014
BSDs
7-10
A B C D E F G H J
1
2
3
4
5
6
10.1 FUSER
PL 4.1
MAIN PWB
2
Fuser Temperature
Signal
OVERTEMPERATURE
THERMOSTAT
FUSER
THERMISTOR
PL 4.1
LVPS PWB
T1 T2
HEAT LAMP
+3.3 VDC
1
P9 J9
ACH
ACN
1
P6J6
3
13
Enable Fuser
Relay
Fuser Relay
On
Heat Lamp
On ACH
+3.3 VDC
PL 5.1
FUSER MODULE
PL 5.1
FUSER MODULE
1
CON J9
2
