Xerox WorkCentre 3225 - Page 183

June 2014
Xerox
®
WorkCentre
®
3215/3225 Multifunction Printer Service Documentation
BSDs
A B C D E F G H J
1
2
3
4
5
6
10.2
10.2 PRINT EXIT
7-11
PL 4.1
MAIN PWB
+3.3 VDC
DC COM
+3.3 VDC
2
1
+3.3 VDC
OUTPUT TRAY FULL
(L) +3.3 VDC
+3.3 VDC
DC COM
EXIT SENSOR
PAPER AT EXIT
SENSOR (L) +3.3 VDC
+3.3 VDC
DC COM
+3.3 VDC
DC COM
PL 4.1
HVPS PWB
3
J8 P8
J2P2
20
P30 J30
7
J100 P100
OUTPUT TRAY FULL
OUTPUT TRAY FULL
SENSOR
PL 4.1
PL 4.3
