Xerox WorkCentre 3225 - Page 184

Xerox
®
WorkCentre
®
3215/3225 Multifunction Printer Service Documentation
June 2014
BSDs
A B C D E F G H J
1
2
3
4
5
6
14.1
14.1 SCANNING
7-12
PL 4.1
MAIN PWB
+3.3 VDC
DC COM
DC COM
PL 7.1
SCANNER PWB
4
3
8
1
J13 P13
1
4
3
8
12
12
+3.3 VDC
DC COM
SIGNAL
2
2
SCAN CONTROL
DC COM
+3.3 VDC
5
5
REFERENCE SIGNAL
6
6
SIGNAL
7
7
CLOCK SIGNAL
+6.6 VDC
+6.6 VDC
+6.6 VDC
DC COM
9
9
CIS BLUE
10
10
CIS GREEN
11
11
CIS RED
DC COM
PL 7.1
SCAN MOTOR
PHASE A
PHASE B
PHASE C
PHASE D
MOT
PL 8.1
CONTROL PANEL PWB
MOTOR
DRIVER
3
2
4
13
3
1
J11 P11
2
1
4
13
SCAN HOME
SENSOR SIGNAL
+5 VDC
DC COM
SCANNER HOME
(H) +5 VDC
+5 VDC
DC COM
+5VDC
2
3
1
SCANNER HOME
SENSOR
3
2
1
4
3
1
2
PHASE A
PHASE B
PHASE C
PHASE D
PL 7.1
