Xerox WorkCentre 3225

June 2014
2-9
Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual
07-500 , 07-530
Status Indicator RAPs
07-500 Manual Feed Slot Paper Empty Fault
The Manual Feed Slot Empty Sensor failed to detect paper in the Manual Feed Slot.
BSD-Reference: 7.1 Paper Feed and Registration
Initial Actions
Ensure that paper is loaded in the tray. Clear any jammed sheets. (Refer to Section 11 in the
WorkCentre® 3215/3225 User Guide for detailed instructions on jam clearance.)
Clean the Manual Feed Slot Empty Sensor.
Procedure
Check the Registration Sensor actuator. The actuator moves freely and is undamaged.
YN
Replace the Registration Sensor Actuator. (REP 1.14). PL 4.4.
Enter Diagnostics Mode, Select [Machine Test, EDC Mode, DC330 Component Control,
102-Sensor, Registration Sensor} to block and clear the Registration Sensor. The sensor
signal changes.
YN
Check for 3.3VDC on the Main PWB. The voltage is present on the Main PWB..
YN
• Replace the HVPS PWB (REP 1.6), PL 4.1.
• Replace the Main PWB (REP 1.8), PL 4.1.
Replace the Feed Sensor PWB (REP 1.14), PL 4.4.
Perform SCP Final Actions.
07-530 Paper Feed Fault - Manual Feed Slot
The lead edge was not detected by the Paper Feed Sensor.
BSD-Reference: 7.1 Paper Feed and Registration
Initial Actions
Clear any jammed sheets. Refer to Section 11 in the WorkCentre® 3215/3225 User Guide for
detailed instructions on clearing paper jams.
Procedure
Check the position of the jammed sheet. The lead edge reached the Retard Roll.
YN
Enter Diagnostics Mode. Select: [Machine Test, EDC Mode, DC330 Component Con-
trol, 102-Sensor, Feed Sens] to block and clear the Feed Sensor. The sensor signal
changes.
YN
1. Check for an open or short circuit.
2. Replace the Paper Feed Sensor (REP 1.14), PL 4.4.
In Diagnostics Mode, select: [101-Clutch, Tray 1 Pick up (Feed)] to engage the drive to
pick up paper from tray 1. The clutch engages.
YN
1. Check for an open or short circuit.
2. Replace the Tray 1 Pick up (Feed Clutch). (REP 1.13), PL 4.1.
Perform SCP Final Actions.
Check the Paper Feed Sensor actuator. The actuator moves freely is and undamaged.
YN
Replace the Paper Feed actuator. (REP 1.14), PL 4.4.
Inspect the Paper Feed Sensor for damage. The sensor is OK.
YN
1. Check for an open or short circuit.
2. Replace the Paper Feed Sensor. (REP 1.14), PL 4.4.
Check the circuit of the Paper Feed Sensor.
