Status Indicator RAPs
07-600 Paper Tray Empty Faults
The Tray 1 Empty sensor and the Registration sensor failed to detect paper in the paper trays.
BSD-Reference: 7.1 Paper Feed and Registration
Initial Actions
Ensure that paper is loaded in the trays. Clear any jammed sheets. (Refer to Section 11 in the
WorkCentre® 3215/3225 User Guide for detailed instructions on jam clearance.)
Procedure
Check the Paper Tray 1 Empty sensor, PL 4.5 and the Registration sensor, PL 4.4 for contami-
nation. The sensors are free of contamination.
YN
Clean the sensors.
Refer to the following RAPs:
• 07-500 Manual Feed Slot Paper Empty Fault
• 07-110 Paper Tray 1 Empty Fault
08-100 Paper Feed Fault - Tray 1
The lead edge was not detected by the Paper Feed Sensor.
BSD-Reference: 7.1 Paper Feed and Registration
Initial Actions
Clear any jammed sheets. (Refer to Section 11 in theWorkCentre® 3215/3225 User Guide for
detailed instructions on jam clearance.)
Procedure
Check the Tray 1 Paper Feed Sensor Actuator. The Actuator moves freely.
YN
Replace the Tray 1 Paper Feed Sensor Actuator PL 4.4.
Check the position of the jammed sheet. The lead edge reached the Retard Roll.
YN
Enter Diagnostics Mode. Select: [Machine Test, EDC Mode, DC330 Component Con-
trol, 101-Clutch, Tray 1 Pick up] to engage the drive to pick up paper from tray 1 The
clutch engages.
YN
1. Check the circuit between the Feed Clutch and the HVPS PWB for an open or
short circuit.
2. Replace the Tray 1 Pick up (Feed) Clutch (REP 1.13), PL 4.1.
Check the Paper Feed Actuator. The actuator moves freely.
YN
Replace the Paper Feed Actuator. (REP 1.13), PL 4.4.
In Diagnostics Mode. Select: [102-Sensor, Feed Sens] to block and clear the Paper
Feed Sensor. The signal changes.
YN
1. Check that there is no contamination present.
2. Check for an open or short circuit.
3. Replace the Paper Feed Sensor PWB, (REP 1.14), PL 4.4.
Perform SCP Final Actions.
Check the circuit of the Paper Feed Sensor.
