Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual
10-100 , 10-200/ 300
Status Indicator RAPs
10-100 Fuser Temperature (Open) Fault
The temperature of the Fuser is outside of the normal operating range of 383°F ± 5°F (195°C ±
5°C.)
BSD-Reference: 10.1 Fusing
Initial Actions
Switch Off the power then switch On the power.
Procedure
WARNING
Do not handle the fuser components until they have cooled. Some fuser components
operate at hot temperatures and can produce serious personal injury if touched.
DANGER: Ne pas manipuler les éléments du four avant de les laisser refroidir. Certains
éléments du four fonctionnent à des températures très élevées et peuvent causer de
graves blessures s'ils sont touchés.
AVVERTENZA: Non maneggiare i componenti del fusore finché non sono raffreddati.
Alcuni di questi componenti funzionano ad alte temperature e possono provocare gravi
ferite se vengono toccati.
VORSICHT: Die Fixieranlage sollte erst gehandhabt werden, wenn diese genügend
abgekühlt ist. Einige Teile der Fixieranlage erzeugen übermäßige Hitze und führen bei
der Berührung zu schweren Verbrennungen.
AVISO: No manipule los componentes del fusor antes de que se enfríen. Algunos de los
componentes del fusor funcionan a altas temperaturas y pueden ocasionar daños per-
sonales graves si se los toca.
Power Off the machine and check that the Fuser connection is fully seated, REP 1.17. The
Fuser connections are OK.
YN
Firmly reconnect the Fuser assembly. Switch the power ON.
Check for +3.3 VDC to the Thermistor on the Main PWB. The voltage is present.
YN
• Check the wire harness for open or short circuits.
• Replace the Main PWB (REP 1.8), PL 4.1.
Check the voltage to the Over Heat Thermostat. The voltage is present.
YN
• Check for AC line voltage to the LVPS PWB. BSD 10.1
• Check for the Over Heat Thermostat for contamination.
• Check the wire harness for open or short circuits.
• Replace the LVPS/HVPS PWB (REP 1.7) PL 4.1.
Check the Heat Lamp for an open circuit.
Repair or replace the Fuser Assembly as required. PL 5.1.
10-200/ 300 Fuser Under/ Over Temperature Fault
The temperature of the Fuser is outside of the normal operating range of 383°F ± 5°F (195°C ±
5°C.)
BSD-Reference: 10.1 Fusing
Initial Actions
Switch Off the power. Remove and reinstall the Fuser Assembly. Switch On the power.
Procedure
WARNING
Do not handle the fuser components until they have cooled. Some fuser components
operate at hot temperatures and can produce serious personal injury if touched.
DANGER: Ne pas manipuler les éléments du four avant de les laisser refroidir. Certains
éléments du four fonctionnent à des températures très élevées et peuvent causer de
graves blessures s'ils sont touchés.
AVVERTENZA: Non maneggiare i componenti del fusore finché non sono raffreddati.
Alcuni di questi componenti funzionano ad alte temperature e possono provocare gravi
ferite se vengono toccati.
VORSICHT: Die Fixieranlage sollte erst gehandhabt werden, wenn diese genügend
abgekühlt ist. Einige Teile der Fixieranlage erzeugen übermäßige Hitze und führen bei
der Berührung zu schweren Verbrennungen.
AVISO: No manipule los componentes del fusor antes de que se enfríen. Algunos de los
componentes del fusor funcionan a altas temperaturas y pueden ocasionar daños per-
sonales graves si se los toca.
Enter Diagnostic Mode. Select: [Machine Test, EDC Mode, DC330 Component Control, 109
Fuser Heat, Temp A] to obtain a temperature reading from the Fuser. The Fuser tempera-
ture is within normal operating range.
YN
Replace the Fuser Assembly (REP 1.17), PL 5.1.
If problem is intermittent, check the circuit of the Fuser Assembly for one of the following:
• All connections are securely connected and no contamination is present.
• Short circuit or damaged wire. Repair as necessary.
