REP 5.28
Repairs and Adjustments
Replacement
1. Check the following (Figure 3).
Figure 3 Checking the DADF Pickup Assembly
2. Reinstallation is the reverse of the Removal procedure.
1
Ensure that the retaining pin is
fully seated inside the coupler.
2
Ensure that the plastic tab is
seated inside the sleeve.
