Xerox WorkCentre 4150 Service Manual

January 2016
6-61
WorkCentre 4150/4250/4260WorkCentre 4150/4250/4260WorkCentre Work-
dC131
General Procedures and Information
20-210 Dial Pulse M/B
Ratio
Dial pulse make/break
ratio.
33/66 (0) or 40/60 (1) 1
20-220 Auto Dial Start
Pause Time
Pause time before auto-
dialing (second)
0 to 10 seconds 1
20-300 Ring On Time Ring on time. 0 to 99msec. 80
20-310 Ring Off Time Ring off time. 0 to 99 msec. 80
20-320 Ring Detection
Frequency (4265
only)
Detects Ring Frequency. 1 1
20-400 DTMF High-Freq
Level
DTMF high frequency
level.
0 to 15dBm 8
20-410 DTMF Low-Freq
Level
DTMF low frequency
level.
0 to 15dBm 11
20-420 DTMF Timing
(4265 only)
DTMF Timing. 8 8
20-500 Dial Mode Dial mode selection. Tone (0) / Pulse (1) 0
20-510 ECM Mode ECM mode on or off. Off (0) / On (1) 0
20-520 Error Rate Adjusts the error rate. Off (0) / 5% (1) / 10% (2) /
20% (3)
0
20-530 Dial Tone Detect
(4265 only).
Detects the Dial Tone. 0 0
20-540 Loop Current
Detect (4265
only)
Detects Loop Current. 0 0
20-550 Busy Signal
Detect (4265
only)
Detects busy signal. 1 1
20-700 Line Monitor
Setting
Audio line monitor. Off (0) / On (1) / Comm (2) 0
Table 8 NVM chain 20
Location NVM Name NVM Description Value Default
20-800 Modem Speed Select modem start
speed.
Modem_V21_300bps (0)
Modem_V27_2400bps (1)
Modem_V27_4800bps (2)
Modem_V29_7200bps (3)
Modem_V29_9600bps (4)
Modem_V33_12000bps (5)
Modem_V33_14400bps (6)
Modem_V17_7200bps (7)
Modem_V17_9600bps (8)
Modem_V17_12000bps (9)
Modem_V17_14400bps (10)
Modem_V34_2400bps (11)
Modem_V34_4800bps (12)
Modem_V34_7200bps (13)
Modem_V34_9600bps (14)
Modem_V34_12000bps (15)
Modem_V34_14400bps (16)
Modem_V34_16800bps (17)
Modem_V34_19200bps (18)
Modem_V34_21600bps (19)
Modem_V34_24000bps (20)
Modem_V34_26400bps (21)
Modem_V34_28800bps (22)
Modem_V34_31200bps (23)
Modem_V34_33600bps (24)
0
20-810 Fax Transmis-
sion Level
Adjusts the fax transmis-
sion level
0 to 15dBm 12
20-830 Auto Dial Time-
out
Adjusts the auto dial tim-
eout
10 to 100 seconds 55
20-840 FAX Batch Send
Enable
Fax batch send enable 0 (off) / 1 (on) 0
20-900 FAX Total Send
Counter
Total of sent fax pages. 0-0xffffffff
20-910 FAX Total
Receive Counter
Total of received fax
pages.
0-0xffffffff
Table 8 NVM chain 20
Location NVM Name NVM Description Value Default
