Xerox WorkCentre 4150 Service Manual

January 2016
6-60
WorkCentre 4150/4250/4260WorkCentre 4150/4250/4260WorkCentre Work-
dC131
General Procedures and Information
NOTE: In Table 6 the only features currently available for the 4265 are 10-155 Labels Temper-
ature Offset, and 10-200 Fuser Life Page Counter.
NOTE: For the 4265 machine, the path to NVM Chain 20 is Diagnostics > Fax & NW Diag-
nostics > dC 131 NVM Read/Write-Fax.
Table 6 NVM chain 10
Location NVM Name NVM Description Value Default
10-100 Standby Temper-
ature Offset
Target temperature during
standby mode.
0 to 15 (4 steps/
5 degrees inter-
val)
10
10-105 Run Temperature
Offset
Target temperature during run
mode.
0 to 10 (3 steps/
5 degree inter-
vals)
5
10-110 Low Power Tem-
perature Offset
Target temperature during
power save mode.
0 to 40 (9 steps/
5 degree inter-
vals)
20
10-115 101-185 mm
Temperature Off-
set
Offset temperature required on
thermistor B for paper width.
0 to 15 (4 steps/
5 degree inter-
vals)
5
10-120 186-216 mm
Temperature Off-
set
Offset temperature required on
thermistor B for paper width.
0 to 15 (4 steps/
5 degree inter-
vals)
5
10-125 60gms Tempera-
ture Offset
Media type offset for fuser roll
temperature.
0 to 15 (4 steps/
5 degree inter-
vals)
5
10-130 90gms Tempera-
ture Offset
Media type offset for fuser roll
temperature.
0 to 10 (3 steps/
5 degree inter-
vals)
5
10-135 Bond Tempera-
ture Offset
Media type offset for fuser roll
temperature.
0 to 10 (3 steps/
5 degree inter-
vals)
5
10-140 Transparency
Temperature Off-
set
Media type offset for fuser roll
temperature.
0 to 10 (3 steps/
5 degree inter-
vals)
5
10-145 Cardstock Tem-
perature Offset
Media type offset for fuser roll
temperature.
0 to 10 (3 steps/
5 degree inter-
vals)
5
10-150 Envelopes Tem-
perature Offset
Media type offset for fuser roll
temperature.
0 to 10 (3 steps/
5 degree inter-
vals)
5
10-155 Labels Tempera-
ture Offset
Media type offset for fuser roll
temperature.
0 to 10 (3 steps/
5 degree inter-
vals)
5
10-200 Fuser Life Page
Counter
(Read only)
10-210 Heat Roll Life
Page Counter
(Read only)
10-220 Pressure Roll Life
Page Counter
(Read only)
10-300 Pick-up Interval
Delay
Change the time interval for
paper pick-up.
0 to 100 msec. 0
10-310 Pick-up Interval
Delay (Special
Paper)
Change the time interval for
paper pick-up.
0 to 100 msec. 0
Table 7 NVM chain 11 (4265)
Location NVM Name NVM Description Value Default
11-100 Platen Leading
Edge
Check for Platen Leading
Edge being within specifica-
tion.
30 30
11-105 Platen Side Edge Check for Platen Side Edge
being within specification.
30 30
11-110 Platen Magnifica-
tion
Check for Platen Magnifica-
tion being within specification.
1000 1000
11-200 DADF Bottom
Leading Edge
Check for DADF Bottom Lead-
ing Edge being within specifi-
cation.
30 30
11-205 DADF Bottom
Side Edge
Check for DADF Bottom Side
Edge being within specifica-
tion.
30 30
11-210 DADF Bottom
Magnification
Check for the DADF Bottom
Magnification being within
specification.
1000 1000
11-300 DADF Top Lead-
ing Edge
Check for DADF Top Leading
Edge being within specifica-
tion.
30 30
11-305 DADF Top Side
Edge
Check for DADF Top Side
Edge being within specifica-
tion.
30 30
11-310 DADF Top Magni-
fication
Check for DADF Top Magnifi-
cation being within specifica-
tion.
1000 1000
Table 8 NVM chain 20
Location NVM Name NVM Description Value Default
20-100 Redial Attempts Number of times to
redial.
1 to 13 7
20-110 Redial interval Time between each
redial.
1 to 15 3
20-200 Pause Dial Time Time of each pause. 0 to 200 (1000 msec.) 4
