Xerox WorkCentre 4150 Service Manual

January 2016
6-59
WorkCentre 4150/4250/4260WorkCentre 4150/4250/4260WorkCentre Work-
dC131
General Procedures and Information
07-450 Side Registration
Tray 4 Duplex
(1st side)
The changed dimension of tray
4 side registration of 1st side in
duplex long and short.
0 to 6 (12 steps /
0.5mm seg.)
3
07-500 Top Registration
Bypass Simplex
The changed dimension of
bypass top registration in sim-
plex.
0 to 6 (12 steps /
0.5mm seg.)
3
07-510 Side Registration
Bypass Simplex
The changed dimension of
bypass side registration in sim-
plex.
0 to 6 (12 steps /
0.5mm seg.)
3
07-520 Top Registration
Bypass Dup_long
(2nd side)
The changed dimension of
bypass top registration of 2nd
side in duplex long.
0 to 6 (12 steps /
0.5mm seg.)
3
07-530 Side Registration
Bypass Dup_long
(2nd side)
The changed dimension of
bypass side registration of 2nd
side in duplex long.
0 to 6 (12 steps /
0.5mm seg.)
3
07-540 Top Registration
Bypass Duplex
(1st side)
The changed dimension of
bypass top registration of 1st
side in duplex long and short.
0 to 6 (12 steps /
0.5mm seg.)
3
07-550 Side Registration
Bypass Duplex
(1st side)
The changed dimension of
bypass side registration of 1st
side in duplex long and short.
0 to 6 (12 steps /
0.5mm seg.)
3
Table 4 NVM chain 8
Location NVM Name NVM Description Value Default
08-100 Pick up roller Life
Page Counter
(Read only)
08-110 Forward roller Life
Page Counter
(Read only)
08-120 Retard Roller Life
Page Counter
(Read only)
08-130 Tray 2 Pick-Up
Roller Life Page
Counter
(Read only)
08-140 Tray 3 Pick-Up
Roller Life Page
Counter
(Read only)
08-150 Tray 4 Pick-Up
Roller Life Page
Counter
(Read only)
08-160 Bypass Rubber
Pad Life Page
Counter
(Read only)
Table 3 NVM chain 7
Location NVM Name NVM Description Value Default
Table 5 NVM chain 9
Location NVM Name NVM Description Value Default
09-100 LD Light Level 600dpi laser light level. Value
in PWM.
(4150) 200 to 600
(4250/4260) 50 to
800
(4265) 175
(4150) 350
(4250/4260)
250
(4265) 175
09-110 MHV Control Bias
Control
Main charge bias control.
Basic of value (HVPS setting
is value). Value in PWM.
(4150) 108 to 145
(4250/4260) 600
to 850
(4150) 126
(4250/4260)
710
09-120 THV Control Bias
Control
Transfer bias control. Basic
of value (HVPS setting is
value). Value in PWM.
(4150) 41 to 220
(4250/4260) 270
to 600
(4150) 76
(4250/4260)
310
09-130 Deve Bias Control Developer bias control.
Basic of value (HVPS setting
is value). Value in PWM
standard voltage: -500V
(PWM 522).
(4150) 408 to 607
(4250/4260) 400
to 650
(4150) 522
(4250/4260)
512
09-140 Detack Bias Con-
trol
Detack bias control. Basic of
value (HVPS setting is
value). Value in PWM stan-
dard voltage: -1800V.
(4150) 80 to 160
(4250/4260) 200
to 730
(4150) 123
(4250/4260)
508
09-150 Altitude Adjust-
ment
Allows adjustment for local
altitude.
00
09-200 Drum Life Page
Counter
Display of drum pages count. (Read only)
09-210 Toner Cartridge
Life Page Counter
Display of toner cartridge
pages count.
(Read only)
09-220 Drum Life Time Displays life of drum Xero-
graphic Drum.
(Read only)
09-230 Transfer Roller
Life Page Counter
Display value of pages
count.
(Read only)
(4265) Not avail-
able.
09-300
(4265)
Dot Count Display value of dots
counted.
Variable 0
09-400
(4265)
Toner Motor Rota-
tion Time
Displays rotations of Toner
Motor.
Variable 0
