dC131
General Procedures and Information
NOTE: If the NVM default characters exceed 10 characters only the first eight characters are
displayed in the list. The full string is displayed in the Read/Write window.
NOTE: Selecting Reset will cause the selected NVM location to be reset to its default value.
Selecting Cancel closes the window and cancels any changes made in the now closed win-
dow.
NOTE: The CSE cannot read or modify any NVM that contains customer administrative or
accounting data.
NOTE: The Read Only (protected) NVM can only be changed using a password obtained from
Xerox.
NOTE: The NVM locations described in Table 1 and Table 2 are not available on the 4265.
Table 1 NVM chain 5
Location NVM Name NVM Description Value Default
05-700 ADF Roller Life
Page Counter
(Read only)
05-710 ADF Rubber Pad
Life Page Counter
(Read only)
Table 2 NVM chain 6
Location NVM Name NVM Description Value Default
06-100 Vertical Magni-
tude
The changed dimension of the
vertical direction magnitude.
0 to 6 (12 steps /
0.5mm seg.)
3
06-110 Horizontal Magni-
tude
The changed dimension of the
horizontal direction magnitude.
0 to 6 (12 steps /
0.5mm seg.)
3
Table 3 NVM chain 7
Location NVM Name NVM Description Value Default
07-100 Top Registration
Tray 1 Simplex
The changed dimension of tray
1 top registration in simplex.
0 to 6 (12 steps /
0.5mm seg.)
3
07-110 Side Registration
Tray 1 Simplex
The changed dimension of tray
1 side registration in simplex.
0 to 6 (12 steps /
0.5mm seg.)
3
07-120 Top Registration
Tray 1 Dup_long
(2nd side)
The changed dimension of tray
1 top registration of 2nd side in
duplex long.
0 to 6 (12 steps /
0.5mm seg.)
3
07-130 Side Registration
Tray 1 Dup_long
(2nd side)
The changed dimension of tray
1 side registration of 2nd side
in duplex long.
0 to 6 (12 steps /
0.5mm seg.)
3
07-140 Top Registration
Tray 1 Duplex
(1st side)
The changed dimension of tray
1 top registration of 1st side in
duplex long and short.
0 to 6 (12 steps /
0.5mm seg.)
3
07-150 Side Registration
Tray 1 Duplex
(1st side)
The changed dimension of tray
1 side registration of 1st side in
duplex long and short.
0 to 6 (12 steps /
0.5mm seg.)
3
07-200 Top Registration
Tray 2 Simplex
The changed dimension of tray
2 top registration in simplex.
0 to 6 (12 steps /
0.5mm seg.)
3
07-210 Side Registration
Tray 2 Simplex
The changed dimension of tray
2 side registration in simplex.
0 to 6 (12 steps /
0.5mm seg.)
3
07-220 Top Registration
Tray 2 Dup_long
(2nd side)
The changed dimension of tray
2 top registration of 2nd side in
duplex long.
0 to 6 (12 steps /
0.5mm seg.)
3
07-230 Side Registration
Tray 2 Dup_long
(2nd side)
The changed dimension of tray
1 side registration of 2nd side
in duplex long.
0 to 6 (12 steps /
0.5mm seg.)
3
07-240 Top Registration
Tray 2 Duplex
(1st side)
The changed dimension of tray
2 top registration of 1st side in
duplex long and short.
0 to 6 (12 steps /
0.5mm seg.)
3
07-250 Side Registration
Tray 2 Duplex
(1st side)
The changed dimension of tray
2 side registration of 1st side in
duplex long and short.
0 to 6 (12 steps /
0.5mm seg.)
3
07-300 Top Registration
Tray 3 Simplex
The changed dimension of tray
3 top registration in simplex.
0 to 6 (12 steps /
0.5mm seg.)
3
07-310 Side Registration
Tray 3 Simplex
The changed dimension of tray
3 side registration in simplex.
0 to 6 (12 steps /
0.5mm seg.)
3
07-320 Top Registration
Tray 3 Dup_long
(2nd side)
The changed dimension of tray
3 top registration of 2nd side in
duplex long.
0 to 6 (12 steps /
0.5mm seg.)
3
07-330 Side Registration
Tray 3 Dup_long
(2nd side)
The changed dimension of tray
3 side registration of 2nd side
in duplex long.
0 to 6 (12 steps /
0.5mm seg.)
3
07-340 Top Registration
Tray 3 Duplex
(1st side)
The changed dimension of tray
3 top registration of 1st side in
duplex long and short.
0 to 6 (12 steps /
0.5mm seg.)
3
07-350 Side Registration
Tray 3 Duplex
(1st side)
The changed dimension of tray
3 side registration of 1st side in
duplex long and short.
0 to 6 (12 steps /
0.5mm seg.)
3
07-400 Top Registration
Tray 4 Simplex
The changed dimension of tray
4 top registration in simplex.
0 to 6 (12 steps /
0.5mm seg.)
3
07-410 Side Registration
Tray 4 Simplex
The changed dimension of tray
4 side registration in simplex.
0 to 6 (12 steps /
0.5mm seg.)
3
07-420 Top Registration
Tray 4 Dup_long
(2nd side)
The changed dimension of tray
4 top registration of 2nd side in
duplex long.
0 to 6 (12 steps /
0.5mm seg.)
3
07-430 Side Registration
Tray 4 Dup_long
(2nd side)
The changed dimension of tray
4 side registration of 2nd side
in duplex long.
0 to 6 (12 steps /
0.5mm seg.)
3
07-440 Top Registration
Tray 4 Duplex
(1st side)
The changed dimension of tray
4 top registration of 1st side in
duplex long and short.
0 to 6 (12 steps /
0.5mm seg.)
3
Table 3 NVM chain 7
Location NVM Name NVM Description Value Default
