Xerox WorkCentre 4150 Service Manual

January 2016
1-8
WorkCentre WorkCentre 4150/4250/4260WorkCentre 4150/4250/42604150/
SCP 5
Service Call Procedures
DADF Rub-
ber Pad Life
Page
DADF retard
pad
The total DADH feeds in
all modes after the last
HFSI reset.
115k feeds PL 5.45 Item 4
DADF Roller
Life Page
DADF feed roll
assembly
The total DADH feeds in
all modes after the last
HFSI reset.
230k feeds PL 5.40 Item 7
Fuser Unit
Life Page
Fuser assem-
bly
The total sides of copies
and prints after the last
HFSI reset. This is reset if
a new fuser is installed.
230k impres-
sions
PL 10.28 Item 1
Heat Roll Life
Page
Fuser heat
roller assem-
bly
The total sides of copies
and prints after the last
HFSI reset.
230k impres-
sions
PL 10.30 Item 10
Pressure Roll
Life Page
Fuser pres-
sure roller
The total sides of copies
and prints after the last
HFSI reset.
230k impres-
sions
PL 10.30 Item 31
Transfer Roll
Life Page
Transfer roll The total sides of copies
and prints after the last
HFSI reset.
115k impres-
sions
PL 7.35 Item 19
Toner Car-
tridge Life
Page (see
NOTE)
Toner car-
tridge
The total sides of copies
and prints after the last
HFSI reset.
12k (starter
module)/23k
impressions
PL 9.10 Item 2
Developer
Cartridge Life
Page (see
NOTE)
Xerographic
module
The total sides of copies
and prints after the last
HFSI reset.
80k impressions PL 9.10 Item 1
Table 5 WorkCentre 4250/4260
Item Component Description
Recommended
life for new
component
installation
Parts list
reference
Table 6 WorkCentre 4265
Item Component Description
Recommended
life for new
component
installation
Parts list
reference
Assembly
ADF Roller
DADF Feed
Roll Assembly
The total DADF feeds in
all modes after the last
HFSI reset.
100k feeds PL 7.15 Item 20
PL 8.10 Item 12
Mea ADF
Rubber
TBD TBD 50k feeds PL 7.25 Item 11
PL 8.10 Item 12
Tray 1 Pickup
Roller
Roll assembly
(pick-up roll,
feed roll,
retard roll)
All sheets fed from tray 1
after last HFSI reset.
250k feeds PL 7.25 Item 11
PL 8.10 Item 12
Tray 2 Pickup
Roller
Roll assembly
(pick-up roll,
feed roll,
retard roll)
All sheets fed from tray 2
after last HFSI reset.
250k feeds PL 7.25
Tray 3 Pickup
Roller
Roll assembly
(pick-up roll,
feed roll,
retard roll)
All sheets fed from tray 3
after last HFSI reset.
250k feeds PL 7.25
Tray Bypass
Pickup Roller
Roll assembly
(pick-up roll,
feed roll,
retard roll)
All sheets fed from
Bypass Tray after last
HFSI reset.
100k impres-
sions
PL 8.20
80K Drum Xerographic
Module
The total sides of copies
and prints after the last
HFSI reset.
80k impressions PL 9.10 Item 1
Toner Black Toner Car-
tridge
The total sides of copies
and prints after the last
HFSI reset.
12K (starter
module) / 25K
impressions
PL 9.10
Transfer
Roller
Transfer roll The total sides of copies
and prints after the last
HFSI reset.
125k impres-
sions
PL 7.35 Item 19
Fuser Fuser Assem-
bly
The total sides of copies
and prints after the last
HFSI reset. This is reset if
a new fuser is installed.
250K impres-
sions
PL 10.28 Item 1
Roller 1 DADF Pickup
Roller
The total sides of copies
and prints after the last
HFSI reset.
50k impressions PL 5.70
Roller 2 DADF Pickup
Roller
The total sides of copies
and prints after the last
HFSI reset.
50K impres-
sions
PL 5.70
