WorkCentre 4150/4250/4260WorkCentre WorkCentre 4150/4250/42604150/

SCP 7

Service Call Procedures

This service manual covers all configurations. Within this manual ignore any references to

options that are not installed.

Table 1 Machine Configurations

Features 4150 4150s 4150x 4150xf 4250 4250s 4250x 4250xf 4260 4260s 4260x 4260xf

Basic copier with paper tray 1 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes

Paper tray 2 Optional Optional Yes Yes Optional Optional Optional Yes Optional Optional Optional Yes

Paper tray 3 Optional Optional Optional Yes Optional Optional Optional Yes Optional Optional Optional No

Paper tray 4 Optional Optional Optional Yes Optional Optional Optional Yes Optional Optional Optional No

HCF No No No No Optional Optional Optional Optional Optional Optional Optional Yes

Bypass tray Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes

Envelope tray Optional Optional Optional Optional No No No No No No No No

Low stand (4 tray configuration) Optional Optional Optional Yes Optional Optional Optional Yes Optional Optional Optional No

High stand (2 tray configuration) Optional Optional Optional No Optional Optional Optional No Optional Optional Optional No

Duplex assembly Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes

50 sheet DADF Yes Yes Yes Yes No No No No No No No No

75 sheet DADF No No No No Yes Yes Yes Yes Yes Yes Yes Yes

Finisher Optional Optional Optional Yes Optional Optional Optional Yes Optional Optional Optional Yes

Direct printing No Yes Yes Yes No Yes Yes Yes No Yes Yes Yes

Network printing No Yes Yes Yes No Yes Yes Yes No Yes Yes Yes

Fax Optional Optional Yes Yes Optional Optional Yes Yes Optional Optional Yes Yes

Scan to e-mail No Yes Yes Yes No Yes Yes Yes No Yes Yes Yes

Foreign device interface (service

install option)

Optional Optional Optional Optional Optional Optional Optional Optional Optional Optional Optional Optional

40Gb hard disk Yes Yes Yes Yes No No No No No No No No

80Gb hard disk No No No No Yes Yes Yes Yes Yes Yes Yes Yes

System memory (128Mb)YesYesYesYesNoNoNoNoNoNoNoNo

System memory (256Mb) No No No No Yes Yes Yes Yes Yes Yes Yes Yes

Additional memory (128Mb) No Yes Yes Yes No No No No No No No No

Extended memory (256Mb) No Optional Optional Optional Optional Optional Optional Optional No Optional Optional Optional
