Installing Staples
WorkCentre 7425/7428/7435
User Guide
187
2. While squeezing orange levers R2 and R3 together (1), pull the staple cartridge unit out of the
finisher until it stops (2).
Note: The staple cartridge unit does not detach from the finisher.
3. Grip the orange tabs on both sides of the staple cartridge.
4. While gripping the orange tabs of the staple cartridge, rotate it in the direction shown.
1
2
wc74xx-104
-
wc74xx-106
