Xerox WORKCENTRE 7425 - Rear-Left View

Features
WorkCentre 7425/7428/7435
User Guide
22
Rear-Left View
1. Top left cover 6. Fax connection (optional)
2. Upper left cover 7. USB connection (optional)
3. Bottom left cover 8. USB memory card connection (optional)
4. Circuit breaker 9. Ethernet connection
5. Parallel connection (optional)
4
5
6
3
2
1
7
9
8
wc74xx-002
