Xerox WORKCENTRE 7425

Features
WorkCentre 7425/7428/7435
User Guide
24
Internal Components
Telephone Connections
1. Drum Cartridge Release Lever
2. Toner Cartridges
3. Transfer Belt Cleaner
4. Waste Toner Container
5. Drum Cartridges
6. Drum Cartridge Cover
7. Transfer Roller
8. Fuser Assembly
1. Tel 3. Line 2
2. Line 1 4. Line 3
1
2
4
3
5
6
8
7
wc74xx-003
TE L LINE1
LINE2
LINE3
4
1
2
3
wc74xx
-
006
