Parts of the Printer
WorkCentre 7425/7428/7435
User Guide
25
Professional Finisher (optional)
1. Front cover 5. Staple cartridge
2. Right top tray 6. Right bottom tray (Booklet Maker)
3. Exit cover 7. Booklet unit
4. Right middle tray 8. Center tray (front transport cover)
Note: Center tray-upper is removed
when a finisher is installed.
wc74xx-008
8
7
1
5
2
6
4
3
