Clearing Staple Jams
WorkCentre 7425/7428/7435
User Guide
229
4. Open the staple cartridge clamp by pulling firmly in the direction shown.
5. Remove the jammed staples (1), then push the clamp in the direction shown until it snaps into the
locked position (2).
Warning: The points of the jammed staples are sharp. Remove the jammed staples carefully.
6. Grip the staple cartridge by the orange tabs and insert it into the staple cartridge unit until it clicks.
7. Close the finisher front door.
wc74xx-121
wc74xx-122
1
2
wc74xx-102
