Xerox WorkCentre Pro 423 Service Manual

WorkCentre Pro 423/428 2-6 CHAPTER 2 TROUBLESHOOTING
03/02 2.3 Level 2 Troubleshooting
Status
Code
Status Description
Corrective
Action
Ref.
BSD
U7-05
(4075)
Inter-system
Communication
Fail
Communication not
established between MF
system and MCU/SW
POWER
OFF/ON
19.2
U7-31
(4371)
Inter-system
Communication
Fail
Initial communication check
error between MCU/SW and
PWB control panel
POWER
OFF/ON Check
connectors.
3.1B
U7-32
(4372)
Inter-system
Communication
Fail
Framing/Overrun/Parity
error between MCU/SW
PWB and CONTROL
PANEL
POWER
OFF/ON
3.1B
U7-33
(4373)
Inter-system
Communication
Fail
BCC error between
MCU/SW PWB and
CONTROL PANEL
POWER
OFF/ON
3.1B
U7-34
(4374)
Inter-system
Communication
Fail
No Communication between
MCU/SW PWB and
CONTROL PANEL
POWER
OFF/ON
3.1B
U7-35
(4375)
Inter-system
Communication
Fail
Communication not
established between
MCU/SW PWB and
CONTROL PANEL
POWER
OFF/ON Check
connectors.
3.1B
U7-41
(4471)
Inter-system
Communication
Fail
Initial communication check
error between MCU/SW
PWB and IIT/IPS PWB
POWER
OFF/ON Check
connectors.
3.1A
U7-42
(4472)
Inter-system
Communication
Fail
Framing/Overrun/Parity
error between MCU/SW
PWB and IIT/IPS PWB
POWER
OFF/ON
3.1A
U7-43
(4473)
Inter-system
Communication
Fail
BCC error between
MCU/SW PWB and IIT/IPS
PWB.
POWER
OFF/ON
Rewrite NVM.
3.1A
U7-44
(4474)
Inter-system
Communication
Fail
No Communication between
MCU/SW PWB and IIT/IPS
PWB
POWER
OFF/ON
Rewrite NVM.
3.1A
U7-45
(4475)
Inter-system
Communication
Fail
Communication not
established between
MCU/SW PWB and IIT/IPS
PWB.
POWER
OFF/ON Check
connectors.
3.1A
Status
Code
Status Description
Corrective
Action
Ref.
BSD
U8-3
(4483)
LAMP/CCD
Sensor failure
AGC FAIL POWER
OFF/ON
6.1B,6.
2
U8-4
(4484)
LAMP/CCD
Sensor failure
AOC FAIL1
POWER
OFF/ON
6.1B,6.
2
U8-5
(4485)
LAMP/CCD
Sensor failure
AOC FAIL2 POWER
OFF/ON
6.1B,6.
2
U8-6
(4486)
LAMP/CCD
Sensor failure
Shading correction value
reading failure
POWER
OFF/ON
6.1B,6.
2
U9-1
(4810)
MCU/SW PWB
failure
MCU/SW PWB connection
failure
POWER
OFF/ON
3.1C
U9-31
(4831)
MCU/SW PWB
failure
MCU/SW PWB self-
propelled synchronous
signal 1 failure
POWER
OFF/ON
3.1C
U9-32
(4832)
MCU/SW PWB
failure
MCU/SW PWB self-
propelled synchronous
signal 2 failure
POWER
OFF/ON
3.1C
U9-33
(4833)
MCU/SW PWB
failure
MCU/SW PWB self-
propelled synchronous
signal 3 failure
POWER
OFF/ON
3.1C
U9-41
(4841)
MCU/SW PWB
failure
MCU/SW PWBIOT
synchro failure
POWER
OFF/ON
3.1C
UE-01
(4901)
EPSV Interface
Error
Login information mismatch POWER
OFF/ON
3.2A
UE-02
(4902)
EPSV Interface
Error
Communication error
between EPSV and related
products.
POWER
OFF/ON Check
connectors.
3.2A
UE-10
(4910)
EPSV Interface
Error
Unable to notify Fuji Xerox
of a machine fault
Press arbitrary
key.
3.2A
UE-11
(4911)
EPSV Interface
Error
Unable to change Install
data
Press arbitrary
key.
3.2A
UE-12
(4912)
EPSV Interface
Error
Unable to clear EPSV alert
information
Press arbitrary
key.
3.2A
UE-13
(4913)
EPSV Interface
Error
Unable to request Fuji
Xerox to recover the U
product
Press arbitrary
key.
3.2A
UE-14
(4914)
EPSV Interface
Error
Unable to transmit NR data
to Fuji Xerox
Press arbitrary
key.
3.2A
