Programmer Operations
HW-130 Programmer User Guide 2-9
1. After programming a device, select the Verify Device
command from the Options menu or click on the Verify
Device toolbar button.
The software compares the device to the file that you loaded into
the programmer memory.
Note: If the programmer memory is empty, you are prompted to
select a file to be downloaded into the programmer memory before
the software can verify the device.
If the device matches the file, the software updates the Device
Checksum and Pass display.
If there are differences, an error message is displayed.
2. Repeat the previous step until you have verified all the copies of
the specified device type either by clicking on the Verify
Device toolbar button or by pressing the programmer push-
button.
Comparing One Device to Another
You can load a device pattern in the programmer memory ready for
the software to compare it to another device. Use the Load Master
toolbar button to do this.
1. After inserting a programmed device in the socket, select Load
Master to load that device pattern into the programmer memory.
2. Remove the device from the socket and insert the device against
which you want to verify the RAM data.
3. Select the Verify Device command from the Options menu or
click on the Verify Device toolbar button shown in Figure 2-
10.
Checking for Blank Device (Ctrl-B)
Use the Blank Check command to ensure that the device in the socket
is blank.
1. After inserting the device in the socket, select the Blank Check
Device command from the Options menu or click on the Blank
