HW-130 Programmer User Guide D-1
Appendix D
Wiring Conventions
This appendix includes wiring information that you can use for
hardware purposes.
Power Cord
The following illustration indicates the wiring of the HW-130
Programmer power cord. The following illustration shows the
commonly used wiring convention for the U.S.A. power cord. Use
the wire colors as a wiring guide.
Figure D-1 Typical U.S.A. Power Cord
Hot/Live
(Black)
Ground
(Green)
Neutral
(White)
Hot/Live
(Black)
Ground
(Green)
Neutral
The colors specified in this diagram are typical.
X4972
(White)
