Getting Started
HW-130 Programmer User Guide 1-3
HW-130 Programmer Description
The HW-130 Programmer comes with the following items:
● RS-232 9-to-9-pin data cable and 9-to-25-pin adapter
● 25-pin female adapter for PC and IBM workstation users
● 25-pin male adapter for Sun workstation users
● HP workstation users do not need a 9-to-25-pin adapter
● Universal Power Supply
● Power Cord
● Software
● User Guide
● Vacuum Handling Tool Kit
The HW-130 Programmer consists of a base with a 96-pin connector
on top of the case to attach the different socket adapters for each
device and package type.
Socket adapters are available for each of the different product
families.
As indicated in Figure 1-1, the top of the programmer case has three
LEDs: red (fail), green (pass), and a power indicator. A push-button is
used for operator responses.
