Xilinx HW-130 - Serial Connector

HW-130 Programmer User Guide
D-2 Xilinx Development System
Serial Connector
The following illustration shows the serial port connections.
Figure D-2 HW-130 Serial Connector
X6044
2
T X D
+8V
3K
9 Pin
DB9 Connector (Female)
3
R X D
8
RTS
7
CTS
6
DSR
5
GND
1
DCD
4
DTR
9
RI
