Xilinx HW-130 - Specifying a Profile; Creating a Profile

Programmer Operations
HW-130 Programmer User Guide 2-5
The design file that you specify is downloaded to the memory of
the HW-130 Programmer when you click on the Design File OK
button. The File Checksum field is updated with the checksum of
the downloaded file.
Note: If an XC1700 design does not fit the targeted device, a message
is displayed, informing you that your design file is too large for the
selected device. In this case, you must select a larger device to fit your
design.
Specifying a Profile
Use the Profile command to define information for a programming
session and save it to a file. You can store setup information for a
selected device, such as a specific design file, secure option, or the
Reset Polarity. When you select a profile, it automatically sets up the
programmer to the desired conditions, with no intervention on your
part. Profile is accessible at any time during a programming session
from the File menu or from the toolbar, enabling you to load a preset
profile.
Figure 2-7 Load Profile Toolbar Button
Creating a Profile
To create a profile, follow these instructions:
1. Select Profile ➝ Create from the File menu.
2. Select a device from the Device List.
3. Select Secure Device(s) or Reset Polarity Active High,
or Reset Polarity Active Low, depending on the device
selected.
4. Click on OK.
5. Select a design file from the Open File dialog box.
6. Click on OK after choosing the correct file.
7. A dialog box appears, displaying the items that you selected to
