HW-130 Programmer User Guide B-1
Appendix B
Diagnostics Procedures
This appendix explains how to monitor the calibration of the HW-130
Programmer and how to run the diagnostic tests.
Auto-Calibration
The HW-130 Programmer automatically calibrates itself whenever
you turn on the power or you use the Reset Programmer command.
However, the HW-130 provides the capability to monitor the
operation of the calibration circuitry. The calibration adapter shown
in the following figure is required.
Figure B-1 Calibration Adapter
X4922
HW-130-CAL
PVpp
Ipp
CLOSED
OPEN
PVcc PVsp
Icc Isp
PVpp PVcc PVsp
+++
1234
R
