HW-130 Programmer User Guide
3-2 Xilinx Development System
Exit Exits the HW-130 software.
Options Menu
The Options menu includes commands to execute programmer
commands and commands to configure and diagnose the
programmer. To access this menu with the keyboard on a PC, press
the letter O, underlined in the menu name, while holding down the
Alt key. Press the underlined letter corresponding to the menu option
you want.
Program Device Programs the selected device with the
selected design.
Verify Device Compares the programmed device to the
file currently loaded in the programmer
memory.
Load Master Loads the contents of a programmed
device into the programmer memory.
Blank Check Device Checks that the device is blank.
Signature String Retrieves the signature of devices.
Device Checksum Checks the device checksum.
Auto-Calibration Measures the voltage and current for
each power supply.
Diagnostics Provides several diagnostics loops to
check the port, memory, pin drivers,
and supply voltage.
Reset Programmer Resets the programmer.
Autohandler Mode Turns the autohandler mode on or off.
Communications Sets the port and baud rate of the
HW-130 Programmer.
Sound Sets the sound on or off.
Help Menu
The Help menu contains commands that enable you to access online
help for the HW-130 Programmer. To access this menu with the
keyboard on a PC, press the letter H, underlined in the menu name,
while holding down the Alt key. Press the underlined letter
corresponding to the menu option you want.
Contents Lists online help topics.
About HW-130 Displays the program version.
