Spartan-3E Starter Kit Board User Guide www.xilinx.com 115
UG230 (v1.0) March 9, 2006
Hirose 100-pin FX2 Edge Connector (J3)
R
Table 15-1:
Hirose 100-pin FX2 Connector Pinout and FPGA Connections (J3)
Signal Name FPGA Pin
Shared Header Connections FX2 Connector
FPGA Pin Signal NameLED J1 J2 JP4 J6
A
(top)
B
(bottom)
VCCO_0 1 1 SHIELD
VCCO_0 2 2 GND GND
TMS_B
3 3 TDO_XC2C
JTSEL
4 4 TCK_B
TDO_FX2
5 5 GND GND
FX2_IO1 B4
6 6 GND GND
FX2_IO2 A4
7 7 GND GND
FX2_IO3 D5
8 8 GND GND
FX2_IO4 C5
9 9 GND GND
FX2_IO5 A6
10 10 GND GND
FX2_IO6 B6
11 11 GND GND
FX2_IO7 E7
12 12 GND GND
FX2_IO8 F7
13 13 GND GND
FX2_IO9 D7
14 14 GND GND
FX2_IO10 C7
15 15 GND GND
FX2_IO11 F8
16 16 GND GND
FX2_IO12 E8
17 17 GND GND
FX2_IO13 F9
LD7 18 18 GND GND
FX2_IO14 E9
LD6 19 19 GND GND
FX2_IO15 D11
LD5 20 20 GND GND
FX2_IO16 C11
LD4 21 21 GND GND
FX2_IO17 F11
LD3 22 22 GND GND
FX2_IO18 E11
LD2 23 23 GND GND
FX2_IO19 E12
LD1 24 24 GND GND
FX2_IO20 F12
LD0 25 25 GND GND
FX2_IO21 A13
26 26 GND GND
FX2_IO22 B13
27 27 GND GND
FX2_IO23 A14
28 28 GND GND
FX2_IO24 B14
29 29 GND GND
FX2_IO25 C14
30 30 GND GND
FX2_IO26 D14
31 31 GND GND
FX2_IO27 A16
32 32 GND GND
FX2_IO28 B16
33 33 GND GND
FX2_IO29 E13
34 34 GND GND
To Next Page
