VLAN Setting
 LAN VLAN Tag: Add VLAN tags to all LAN packets.
 LAN VLAN ID: VLAN ID for LAN.
 WAN VLAN Tag: Add VLAN tags to all WAN packets
 WAN VLAN ID: VLAN ID for WAN.
Test Traffic
 Packet Length: The length of test packets (from
64~1600 Bytes) transmitting by NuStreams-P5G/P9A.
 WAN to LAN Utilization (%): The traffic flow ratio from
WAN to LAN, presented in percentage (1~99).
 Test Time: The duration of time for DUT test.
 LAN to WAN Utilization (%): The traffic flow ratio from
LAN to WAN, presented in percentage (1~99).
 Learning Time: NuStreams-P5G/P9A will start sending
send learning packets to the DUT. The DUT will record
the MAC addresses of these packets, and learn the
routing to NuStreams-P5G/P9A.
 Switch Utilization (%): The traffic flow ratio of the
network, presented in percentage (1~99).
 Flow Control: When Flow Control is enabled, the transmitting rate will drop if traffic overflow occurs.
Pass/Fail Criteria
 Loss Tolerance (pkts): The acceptable number of lost
packets in data transmitting during tests (0~9999).
 Excess Tolerance (pkts): The acceptable number of
excess packets in data transmitting during tests
(0~9999).
Apply Run
 Click this button to apply all the settings you’ve made and save the settings to NuStreams-P5G/P9A.
