5.4. NuSet-MiniPG-UG Functions
5.4.1. NuSet-MiniPG-UG Functions Overview
If you choose System Upgrade from NuSet-MiniPG Option Menu,
NuSet-MiniPG-UG’s main window will pop up as shown below:
Function Descriptions
A
Menu Bar
The Menu Bar allows you to update NuStreams-P5G/NuStreams-P9A/
NuPAD’s firmware, FPGA and NuSet-MiniPG license.
B
Quick Launch
Buttons
With a simple click of these Quick Launch Buttons, you can reconnect to
disconnected NuStreams-P5G/P9A and updating firmware, FPGA and
license.
C
Info Select List
This section displays NuStreams-P5G/P9A’s information.
D
Main Display
Window
This section displays detailed system information.
E
USB Connection
Status
This icon shows the connection status between your PC and
NuStreams-P5G/P9A.
