SonTek RS5 User Manual (August 2020) 22
Resolution
0.001m/s
Accuracy (Long Term Average)
1%±0.002m/s
Cell Size
2.5cm to 30cm
Min Profiling Depth
0.15m
Max Profiling Depth
5.0m
First Cell Start(Min) @
5cm from system tip
# Of Cells
Up To 128
Temperature Sensor
Resolution: ±0.01°C
Accuracy: ±0.5°C
Compass/Tilt Sensor
Range: ±180
o
Pitch/Roll, 0-360
o
Heading
Heading Accuracy: ±2°
Pitch/Roll Accuracy: ±1°
Radio/Communication Protocol
Protocol: SonTek Bluetooth
Range: 100m
RS5
Temperature
RS5 Operating
0° to 45°C (32°F to 113°F)
RS5 Storage
-20° to 70°C (-4°F to 158°F)
RS5 Storage w/ Battery
-20° to 45°C (-4°F to 113°F)
Remove batteries from the RS5 if storage
temperatures exceed the storage
temperature of the Li-Ion battery.
RS5 Physical
Specifications
RS5 (Instrument body +
battery cover)
(L) 24.13 cm (9.5 in); (W) 5.08 cm (2.0 in)
RS5 (Instrument body)
(L) 20.96 cm (8.3 in); (W) 5.08 cm (2.0 in)
RS5 Weight in Air
0.45 kg (1.0 lbs)
RS5 Weight in Water
0.15 kg (0.33 lbs)
Waterproof Rating
IP-67
Battery
Physical
Specifications
Battery
19.2mm x 69.7mm
Battery Weight
50g
Battery
Power
Input Battery Voltage
3.3-4.2 VDC
Power
Source
Li-Ion
1 x size 18650, Tenergy, Type 30016-04,
3.7VDC, 2600mAh
