104
Carrying Handle MHG-1
• Do not install the supplied MHG-1 Mounting Screws if you are not installing the MHG-1.
• Do not use an improper screw for mounting the MHG-1! An improper screw may cause a “short circuit” to
the internal circuitry, causing serious damage.
Screw the Carrying Handle to the FT-710 using the supplied screws.
Handle
Handle end
Handle end
Mounting Screw
Mounting Screw
Mounting Bracket SMB-209
• Do not install the supplied SMB-209 Mounting Screws if you are not installing the SMB-209.
• Do not use an improper screw for mounting the SMB-209! An improper screw may cause a “short circuit” to
the internal circuitry, causing serious damage.
To Next Page
