Yamaha F90D - Page 123

6D81G11
6-4
1
2
3
4
5
6
7
8
9
Lower unit
6
No. Part name Q’ty Remarks
1 Lower unit 1
2Hose 1
3 Check screw 1
4Gasket 2
Not reusable
5 Dowel 2
6 Bolt 4 M10
×
40 mm/L-transom model
7Drain screw 1
8Grommet 1
9 Bolt 1 M10
×
45 mm
10 Bolt 1 M8
×
60 mm/L-transom model
11 Spacer 1
12 Propeller 1
13 Washer 1
14 Washer 1
15 Cotter pin 1
Not reusable
16 Nut 1
17 Trim tab 1
Special service tools / Lower unit
