Yamaha F90D - Page 124

LOWR
Lower unit
6-5
6D81G11
6
No. Part name Q’ty Remarks
18 Dowel 2 X-transom model
19 Extension 1 X-transom model
20 Stud bolt 4 M10
×
180 mm/X-transom model
21 Washer 4 X-transom model
22 Spring washer 4 X-transom model
23 Nut 4 X-transom model
24 Bolt 1 M8
×
190 mm/X-transom model
