LOWR
Lower unit
6-23
6D81G11
2. Align the alignment mark
a
on the bush-
ing with the alignment mark
b
on the
bracket.
3. Install the dowels
1
into the lower unit.
4. Install the lower unit into the upper case,
and then tighten the lower case mounting
bolts (nuts) to the specified torque.
È
X-transom model
5. Install the trim tab
2
to its original posi-
tion, and then connect the speedometer
hose
3
.
Shift rod push arm: YB-06052
S6D81040
a
b
Lower case mounting bolt (nut):
39 N·m (3.9 kgf·m, 28.8 ft·lb)
S6D86180
2
3
LT
572
LT
To Next Page
