Yamaha F90D - Page 154

6D81G11
7-4
1
2
3
4
5
6
7
8
9
7
No. Part name Q’ty Remarks
18 Bottom cowling 1
19 Grommet 4
20 Collar 4
21 Bolt 1 M6
×
20 mm
22 Holder 1
23 Bolt 2 M6
×
20 mm
24 Bracket 1
25 Bolt 3 M6
×
25 mm
26 Plate 3
27 Power trim and tilt switch 1
28 Grommet 1
29 Grommet 3
30 Bolt 1 M6
×
20 mm
31 Plate 1
32 Grommet 1
33 Screw 2 ø6
×
19 mm
34 Bracket 1
S6D87020
1
21
22
23
25
28
29
26
25
25
26
30
31
26
42
41
43
44
45
46
24
9
10
11
14
12
27
2
3
4
5
5
6
7
8
13
15
16
17
47
18
19
20
32
33
34
35
36
37
38
39
40
48
AA
AA
LT
572
LT
T
R
.
.
2 N
·
m (0.2 kgf
·
m, 1.5 ft
·
Ib)
Bottom cowling
