Yamaha F90D - Page 155

BRKT
Bracket unit
7-5
6D81G11
7
No. Part name Q’ty Remarks
35 Adapter 1
36 Gasket 1
37 Joint 1
38 Joint 1
39 Plastic tie 1
Not reusable
40 Hose 1
41 Bolt 1 M6
×
20 mm
42 Bolt 2 M6
×
25 mm
43 Retaining plate 1
44 Bolt 1 M6
×
20 mm
45 Plate 1
46 Grommet 1
47 Rubber seal 1
48 Clamp 1
S6D87020
1
21
22
23
25
28
29
26
25
25
26
30
31
26
42
41
43
44
45
46
24
9
10
11
14
12
27
2
3
4
5
5
6
7
8
13
15
16
17
47
18
19
20
32
33
34
35
36
37
38
39
40
48
AA
AA
LT
572
LT
T
R
.
.
2 N
·
m (0.2 kgf
·
m, 1.5 ft
·
Ib)
