Yamaha FT60D - Page 155

6C13G11
6-12
1
2
3
4
5
6
7
8
9
Drive shaft and lower case (F50, F60)
6
No. Part name Q’ty Remarks
1Seal 1
2 Oil seal housing 1
3O-ring 1
Not reusable
4 Oil seal 2
Not reusable
5 Washer 1
6 Drive shaft 1
7 Forward gear 1
8 Taper roller bearing assembly 1
Not reusable
9 Forward gear shim —
10 Needle bearing 1
11 Pinion 1
12 Nut 1
13 Lower case 1
14 Sleeve 1
15 Pinion gear shim —
16 Taper roller bearing assembly 1
Not reusable
17 Shift cam 1
Propeller shaft housing (F50, F60) / Drive shaft and lower case (F50, F60)
