Yamaha FT60D - Page 202

BRKT
Bracket unit
7-5
6C13G11
7
No. Part name Q’ty Remarks
18 Grease nipple 1
19 Engine start switch housing 1
20 Engine start switch 1
21 Nut 1
22 Bolt 1 M6
×
25 mm
23 Screw 1 ø6
×
24 mm
24 Bolt 1 M6
×
20 mm
25 Cover 1
26 Power trim and tilt switch 1
27 Screw 5 ø6
×
15 mm
28 Screw 2 ø6
×
15 mm
29 Screw 2 ø6
×
40 mm
30 Throttle grip 1
31 Screw 1 ø6
×
21 mm
32 Washer 1
33 Spring 1
34 Bushing 1
2
3
5
4
6
1
7
8
9
11
10
12
13
14
15
17
16
19
20
19
24
23
22
21
18
34
33
32
31
25
26
30
27
28
29
8
LT
572
LT
LT
242
AA
AA
AA
LT
572
LT
LT
572
LT
T
R
.
.
2 N
·
m (0.2 kgf
·
m, 1.5 ft
·
Ib)
T
R
.
.
37 N
·
m (3.7 kgf
·
m, 27.3 ft
·
Ib)
T
R
.
.
37 N
·
m (3.7 kgf
·
m, 27.3 ft
·
Ib)
T
R
.
.
3 N
·
m (0.3 kgf
·
m, 2.2 ft
·
Ib)
T
R
.
.
4 N
·
m (0.4 kgf
·
m, 3.0 ft
·
Ib)
