Yamaha FT60D - Page 213

6C13G11
7-16
1
2
3
4
5
6
7
8
9
7
No. Part name Q’ty Remarks
1 Exhaust guide 1
2 Oil seal 1
Not reusable
3Hose 1
4 Joint 1
5 Housing 1
6Gasket 1
Not reusable
7 Oil strainer 1
8Bolt 6 M6
×
30 mm
9Gasket 1
Not reusable
10 Oil pan 1
11 Pipe 1 1
12 Pipe 2 1
13 Dowel 2
14 Gasket 1
Not reusable
15 Exhaust manifold 1
16 Bolt 3 M6
×
60 mm
17 Washer 3
S6C17100
4
9
5
13
6
10
7
16
17
22
20
21
23
8
15
18
14
26
3
1
2
21
24
25
19
13
27
12
11
AA
LT
572
LT
AA
LT
572
LT
AA
LT
572
LT
T
R
.
.
10 N
·
m (1.0 kgf
·
m, 7.4 ft
·
Ib)
T
R
.
.
10 N
·
m (1.0 kgf
·
m, 7.4 ft
·
Ib)
T
R
.
.
27 N
·
m (2.7 kgf
·
m, 20.0 ft
·
Ib)
Upper case
