Yamaha QL5 Reference Manual

Recorder
Reference Manual
179
 Transport field
Here you can operate the transport of Nuendo Live.
7 GO TO PROJECT START button
Returns the location to the start of the project.
8 GO TO PREVIOUS MARKER button
Returns the location to the previous marker.
9 GO TO NEXT MARKER button
Advances the location to the next marker.
0 GO TO PROJECT END button
Advances the location to the end of the project.
A CYCLE button
Turns repeat on/off for the project.
B STOP button
Stops playback/recording of the project.
C PLAY button
Starts playback of the project.
D RECORD button
Starts/stops recording of the project.
E EASY RECORDING button
Immediately starts recording on all tracks.
When you press this, the location will move to the last-recorded position, all tracks will
be set to record mode, recording will begin, the record panel will be displayed, and the
panel will be locked. The recording will be started retrospectively.
(Initial setting: 10 seconds)
F Record lock button
Turns recording status lock on/off. This prevents recording from being accidentally
stopped during recording.
G DVS information display
Shows the device label of the selected DVS.
H ADD MARKER button
Adds a marker to the project at the current location.
I RECALL LINK button
Specifies whether a marker will be created when you recall a scene. If this function is
turned on, the button will be lit.
NOTE
Transport functions can also be controlled from USER DEFINED keys (page 194).
Specifying DVS or Dante Accelerator
Before you proceed, use DANTE SETUP to specify the I/O devices that will be mounted. For
details, refer to “Mounting an I/O device on the Dante audio network” on page 224.
NOTE
• You can specify either DVS or Dante Accelerator in the NUENDO LIVE SETUP window.
• However, do not select the same DVS or Dante Accelerator from multiple QL series consoles.
NUENDO LIVE SETUP window
In this window, specify the device that the console will use for communication when working
with Nuendo Live.
STEP
1. In the Nuendo Live screen, press the NUENDO Live SETUP button.
2. In the NUENDO LIVE SETUP window, press the setting method select button.
3. Use the [TOUCH AND TURN] knob to make settings.
4. When you have finished making settings, press the OK button to close the window.
1

Yamaha QL5 Specifications

General

DJ mixer	-
Product color	Black
Video capability	No
Channels quantity	72 channels
Supported sample rates	44.1, 48 kHz
Digital sound processing	- bit
Phantom power	48 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	200 W
Total Harmonic Distortion (THD)	0.05 %

Weight and Dimensions

Depth	563 mm
Width	828 mm
Height	272 mm
Weight	21800 g
