Yamaha QL5 Reference Manual

Data List
24
OUTPUT EQ
ON
MIX 1–MIX 16
MATRIX 1–MATRIX 8
STEREO L–MONO(C)
LOW Q
LOW FREQ
LOW GAIN
LOW MID Q
LOW MID FREQ
LOW MID GAIN
HIGH MID Q
HIGH MID FREQ
HIGH MID GAIN
HIGH Q
HIGH FREQ
HIGH GAIN
LOW TYPE
HIGH TYPE
LOW HPF ON
HIGH LPF ON
PAN/BALANCE INPUT
CH 1–CH 64
*1
STIN1L–STIN8R
PEQ
A/B LINK
GEQ RACK 1A–8B
EFFECT RACK 1A–8B
ON
BAND1 BYPASS
BAND1 GAIN H
BAND1 GAIN L
BAND1 FREQ
BAND1 Q
BAND2 BYPASS
BAND2 GAIN H
BAND2 GAIN L
BAND2 FREQ
BAND2 Q
BAND3 BYPASS
BAND3 GAIN H
BAND3 GAIN L
BAND3 FREQ
BAND3 Q
BAND4 BYPASS
BAND4 GAIN H
BAND4 GAIN L
BAND4 FREQ
BAND4 Q
BAND5 BYPASS
BAND5 GAIN H
BAND5 GAIN L
BAND5 FREQ
BAND5 Q
BAND6 BYPASS
Mode Parameter 1 Parameter 2
PEQ
BAND6 GAIN H
GEQ RACK 1A–8B
EFFECT RACK 1A–8B
BAND6 GAIN L
BAND6 FREQ
BAND6 Q
BAND7 BYPASS
BAND7 GAIN H
BAND7 GAIN L
BAND7 FREQ
BAND7 Q
BAND8 BYPASS
BAND8 GAIN H
BAND8 GAIN L
BAND8 FREQ
BAND8 Q
HPF ON
HPF FREQ
HPF SLOPE
LPF ON
LPF FREQ
LPF SLOPE
NOTCH A ON
NOTCH A FREQ H
NOTCH A FREQ L
NOTCH A Q
NOTCH B ON
NOTCH B FREQ H
NOTCH B FREQ L
NOTCH B Q
NOTCH C ON
NOTCH C FREQ H
NOTCH C FREQ L
NOTCH C Q
PHASE INPUT
CH 1–CH 64
*1
STIN1L–STIN8R
PREMIUM EFFECT A
BYPASS
RACK1–8
PARAM 1 H–PARAM 64 L
PREMIUM EFFECT B
BYPASS
RACK1–8
PARAM 1 H–PARAM 64 L
RECALL SAFE ON
CH 1–CH 64
*1
STIN1L–STIN8R
MIX 1–MIX 16
MATRIX 1–MATRIX 8
STEREO L–MONO(C)
GEQ RACK 1A–8B
EFFECT RACK 1A–8B
PREMIUM RACK 1A–8B
DCA 1–DCA16
Mode Parameter 1 Parameter 2

Yamaha QL5 Specifications

General

DJ mixer	-
Product color	Black
Video capability	No
Channels quantity	72 channels
Supported sample rates	44.1, 48 kHz
Digital sound processing	- bit
Phantom power	48 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	200 W
Total Harmonic Distortion (THD)	0.05 %

Weight and Dimensions

Depth	563 mm
Width	828 mm
Height	272 mm
Weight	21800 g
