Yamaha QL5 - Page 270

Data List
25
STEREO TO MATRIX
MATRIX 1 POINT–MATRIX 8 POINT
STEREO L–MONO(C)
MATRIX 1 ON–MATRIX 8 ON
MATRIX 1 LEVEL H–MATRIX 8 LEVEL H
MATRIX 1 LEVEL L–MATRIX 8 LEVEL L
MATRIX 1/2 PAN–MATRIX 7/8 PAN
SURROUND MONITOR
SOURCE SELECT
—
2CH MONITOR ASSIGN
DOWNMIX
SURROUND SPEAKER SOLO
SURROUND SPEAKER L
SURROUND SPEAKER R
SURROUND SPEAKER C
SURROUND SPEAKER LFE
SURROUND SPEAKER Ls
SURROUND SPEAKER Rs
SURROUND PAN
LR PAN
SELECTED CH
CH 1–CH 64
*1
STIN1L–STIN8R
FR PAN
FR PAN REVERSE
DIV
L ON
R ON
C ON
LFE ON
Ls ON
Rs ON
LFE LEVEL H
LFE LEVEL L
TO MONO ON
CH 1–CH 64
*1
STIN1L–STIN8R
TO STEREO ON
CH 1–CH 64
*1
STIN1L–STIN8R
*1. QL1: CH1-CH32
*2. QL1: INPUT 9-10-INPUT 15-16
Mode Parameter 1 Parameter 2
