TIGHTENING TORQUES
SPEC 0*
NOTE :
1.
First,tighten the upper bearing inner race approximately 7Nm(0.7m»kg, 5.1ft»lb) by using the
torque wrench and check turn steering shaft smoothly.
2.
Second,hold the upper bearing inner race and tighten the ring nut 30Nm(3.0m»kg, 21.7ft»lb) by
using the torque wrench.
3. Final,operate the steering shaft together with the steering stem nut now.
© Upper bearing inner race
(2) Ring nut
2-22
